large parking lot tent event tent

More information is provided by Superb TentProduct Description1. Application:The big clear span tents(SS series, A frame tent) can be widely used as the wedding tent, party tent, exhibition tent, conference tent, different kinds of festivals tent, hajj tent, corporate events te

Featured Products

More information is provided by Superb Tent
Product Description

1. Application:

The big clear span tents(SS series, A frame tent) can be widely used as the wedding tent, party tent, exhibition tent, conference tent, different kinds of festivals tent, hajj tent, corporate events tent, sports tent, & temporary, semi-permanent or permanent building purpose etc.

2. Materials:
Fabric: Double PVC coated polyester fabric, 650-900g/sq. M, water proof, UV resistance, anti-mildew, self-cleaning, fire retardant according to standard NFPA701 & DIN4102 B1/M2

Frame: Hard pressed extruded aluminum 6061/T6, anodized surface finishing.
Main frame profile size: 100X48X3mm;

Connections: Hot-DIP galvanized steel;

3. Life span of fabric(cover & sidewalls): 8-10years;
Life span of aluminum frame: 20-30years

4. Structure safety parameters:
Wind load: 80km/h (0.5kn/M2)
Snow load: 25kg/sq. M

5. Color available: White, red, yellow, blue, green, black, grey, transparent etc

6. Optional Accessories:
Ground anchor, anchor puller, weight plate, glass door, fire door, glass wall, ABS hard wall, Sandwich walls, auto-rolling door, decoration lining, flooring system, clear PVC windows sidewalls, transport rack for the glass door & walls, ramp etc; Chairs, tables, & other furniture for the parties are also provided for your option.

7. Specification for the big clear span tents (MS series, A frame), pls refer to below chart
TypeSpan (m)Side height (m)Ridge height (m)Bay Distance (m)Roof PitchLongest Component (m)Wind Load (km/h)
SS3/2.6-332.63.2320°3.580
SS4/2.6-342.63.4320°4.180
SS6/2.6-362.63.7320°3.580
SS8/2.6-382.64.1320°4.380
SS9/2.6-392.64.3320°4.880
SS10/2.6-3102.64.5320°5.380

SS12/2.6-3122.64.8320°3.280
Main frame Profile100x48x3mm (4-channel)
Eave ConnectionHot-dip Galvanized Twin Steel Plate
Roof FixingBar Tension
Frame MaterialHard Pressed Extruded Aluminum 6061/T6
Cover MaterialDouble PVC coated Polyester textile, flame retardant to DIN4102 B1,M2,650-900g/sq.m
